IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 9 Renewal Parts 9 - 35
Section 9-8 Top Console parts (cont’d)
*5207000-72 will be ready with R4.x production.
**5207000-52 is similar to 5207000-42 but includes the new Valox Bezel.
***5207000-7 was separated into two kits, one kit for the TGC Slide Pots and another kit for
the Rotary knobs.
Table 9-12 New Lower Op Panel FRUs Compatible Configurations
Part Name
Description /
Comments
New Part
Number
Replaces
Part Number(s)
Compatibility
LE9 Lower Op Panel
w BOURNS slide pots
- no trackball
Lower Op Panel with BOURNS Slide Pots
5207000-62
5207000-72*
5207000-52**
5207000-42
Backward
compatible
Part includes:
• Lower Bezel - Valox
• BOURNS TGC Slide Pots and knobs
Lower Bezel
LE9 - Valox
Lower Bezel – Valox 5207000-14 5207000-11
Backward
compatible
LE9 Lower Circuit
Board for OP
Panel - Bourns Slide
Pots - spare part only
Lower Circuit Board for OP Panel
(including the BOURNS Slide Pots)
5207000-38 5207000-28
Backward
compatible
Includes the new
knobs for the new
TGC Slide Pots.
Part includes:
• 1 Left Elastomer
• 1 Right Elastomer
• 1 Slide Pot Gasket
• 1 Switch, PCB
• 8 BOURNS knobs compatible with
BOURNS Slide Pots
See: FRU image for contents.
LE9 Rotary
Knob Kit - spare part
only
Rotary Knob Kit - Spare Part only
5207000-8 5207000-7***
Backward
compatible
Kit includes:
• 2 Joystick knobs (near trackball)
• 6 Joystick knobs (for other locations on Op Panel)
• 4 Mode Select knobs
See: FRU image for contents.
LE9 TGC Slide Pot
Knob Kit - Spare Part
only Knobs for ALPHA
and for BOURNS
version slide pots.
TGC Slide Pot Knob Kit -
Spare Part only
5207000-9 5207000-7***
Backward
compatible
Includes:
• Knobs for ALPHA (old style) Slide Pot
• Knobs for BOURNS (new style) Slide Pot
• Instruction Sheet
See: FRU image for contents.
