IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 7
Section 8-4
Loading / Reloading / Upgrading the Software
8-4-1 Purpose of this section
This section describes how to install and/or reinstall software on LOGIQ E9.
8-4-2 LOGIQ E9 models versus software requirement
8-4-3 Tools provided with the LOGIQ E9 or as part of an upgrade
• CD with LOGIQ E9 System software
• CD with LOGIQ E9 Application software
If a patch software CD has been included:
• CD with a Patch for LOGIQ E9
Verify that the software is current. Updated software may be available. Check for any available
FMIs.
NOTE: Service Dongle is not required and should NOT be installed during the software loading
session.
Table 8-2 LOGIQ E9 Software Configurations and Hardware/Software Compatibility -
Upgrade Options
CONSOLE
MODEL
NUMBER
DESCRIPTION SOFTWARE VERSION
Phase I BT2010 BT2011 BT2013 BT2014
1.0.3 1.0.4 1.0.5 1.0.6 2.0.3 2.0.4 2.0.5 3.1.2 3.1.3
4 Rev.
x.x
5 Rev.
x.x
5205000
LOGIQ E9,
00-240 VAC
YYYYUUUUUUU
5205000-2
LOGIQ E9,
220-240 VAC
YYYYUUUUUUU
5205000-3
LOGIQ E9,
100-240 VAC
NNNNYYYUUUU
5205000-4
LOGIQ E9,
220-240 VAC
NNNNYYYUUUU
5205000-5
LOGIQ E9,
100-240 VAC
NNNNNNNYYUU
5205000-6
LOGIQ E9,
220-240 VAC
NNNNNNNYYUU
5205000-7
LOGIQ E9,
100-240 VAC
NNNNNNNNNUU
5205000-8
LOGIQ E9,
100-240 VAC
NNNNNNNNNUY

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
