9 - 4 Section 9-5 - LOGIQ E9 Models and hardware/software compatibility
Section 9-5
LOGIQ E9 Models and hardware/software compatibility
LOGIQ E9 Software Configurations Key
Front End Processor - see: 9-12-2 "Front End Boards Compatible Configurations" on page 9-59
Back End Processor - see: 9-13-1 "Back End Boards Compatible Configurations" on page 9-71
Table 9-3 LOGIQ E9 Software Configurations and Hardware/Software Compatibility -
Upgrade Options
CONSOLE
MODEL
NUMBER
DESCRIPTION SOFTWARE VERSION
Phase I BT2010 BT2011 BT2013 BT2014
1.0.3 1.0.4 1.0.5 1.0.6 2.0.3 2.0.4 2.0.5 3.1.2 3.1.3
4 Rev.
x.x
5 Rev.
x.x
5205000
LOGIQ E9,
00-240 VAC
YYYYUUUUUUU
5205000-2
LOGIQ E9,
220-240 VAC
YYYYUUUUUUU
5205000-3
LOGIQ E9,
100-240 VAC
NNNNYYYUUUU
5205000-4
LOGIQ E9,
220-240 VAC
NNNNYYYUUUU
5205000-5
LOGIQ E9,
100-240 VAC
NNNNNNNYYUU
5205000-6
LOGIQ E9,
220-240 VAC
NNNNNNNYYUU
5205000-7
LOGIQ E9,
100-240 VAC
NNNNNNNNNYU
5205000-8
LOGIQ E9,
100-240 VAC
NNNNNNNNNNY
LOGIQ E9 Software Configurations Key
Y Original
U Upgrade available
N Not supported

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
