IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 9 Renewal Parts 9 - 3
Section 9-4
Parts list groups
Table 9-2 Parts List Groups
TABLE NO. DESCRIPTION PAGE NUMBER
Table 9-3
LOGIQ E9 Software Configurations and Hardware/Software Compatibility - Upgrade
Options
9-4
Table 9-4
LOGIQ E9 Software
9-5
Table 9-10
Covers - LOGIQ E9 (not all covers or items listed are identified in Figure 9-2 on page 9-
9)
9-9
Table 9-11
Top Console parts
9-35
Table 9-15
XYZ Mechanism parts
9-38
Table 9-17
Main Console parts
9-42
Table 9-18
Identifying Base Casting for proper Bottom Air Filter Assembly
9-44
Table 9-19
Subwoofer Details
9-45
Table 9-20
Casters (Wheels) parts
9-46
Table 9-21
Card Rack parts
9-48
Table 9-27
Back End Processor parts for R3.x and earlier
9-64
Table 9-28
Back End Processor parts for R4.x and later
9-68
Table 9-30
Power Supply parts
9-72
Table 9-31
Printer
9-77
Table 9-32
Digital Video Disc (DVD) parts
9-79
Table 9-36
Mains Power Cables
9-82
Table 9-37
Top Console cables
9-86
Table 9-38
XYZ Motor/Brake Control cables
9-87
Table 9-39
Main Power Supply Cables
9-89
Table 9-40
Card Rack Cables
9-91
Table 9-41
Back End Processor (BEP) Internal Cables BEP5.x (R3.x and earlier)
9-96
Table 9-42
Back End Processor (BEP) Internal Cables BEP6.x (R4.x and later)
9-97
Table 9-43
Back End Processor (BEP) External Cables
9-100
Table 9-45
Peripherals Cables
9-100
Table 9-46
Supported Probes (not including Japan Probes)
9-102
Table 9-47
Options
9-106
Table 9-49
Product Labels on LOGIQ E9 consoles used in a veterinary environment
9-111
