IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 56 Section 8-5 - Replacing Covers and Bumpers
8-5-11-5 Rear Cover installation
1.) Position the lower edge of the Rear Cover into place on the rear of the system frame.
2.) Tilt the top edge of the Rear Cover toward the system frame.
Be sure the manual release handle of the Z Mechanism extends through the air vent on the Rear
Cover.
3.) Position the Rear Cover into place.
4.) Gently pull up on the Z Mechanism’s manual release handle to confirm proper position through the
Rear Cover air vents.
5.) Install the four screws, two on each side.
6.) Inspect the Filter, and clean in necessary.
7.) Install the Filter.
8.) Install the Filter Cover
9.) Re-install the V Nav On-Board Stand if present.
Figure 8-22 Z Mechanism manual release handle

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
