GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 70 Section 8-5 - Replacing Covers and Bumpers
8-5-16-5 Rear Handle installation
1.) Install the Rear handle in position so the fastening holes are flush with the holes in the frame.
2.) Install the two screws for the Rear Handle (torque 3 Nm {2.2 lbf-ft}).
3.) Install the four hexcap screws for the Rear Handle.
4.) Install the Top Cover.
5.) Install the Rear Cover.
6.) Install the Side Covers.
8-5-16-6 Calibration and adjustments
No calibrations or adjustments are needed after this part replacement.
8-5-16-7 Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) If finished, connect cables and Probes removed earlier.
3.) Power up the system to verify that it operates as intended.
8-5-16-8 Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
If all are successful, include the following debrief script: LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all required checks and is ready for use.
Table 8-47 Rear Handle replacement Functional Checks
See:
Section
Functional Check Debrief Script
4-2-2 Power ON/Boot Up
LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all
required checks and is ready for use.
4-2-3 Power shut down
4-3-14 Probe/Connectors Checks
4-3-5 B-Mode Checks
4-3-7 System CFM and PWD Checks
4-3-18 Mechanical Function Checks
4-3-18-2 Brakes and Direction Lock Checks
