GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 194 Section 8-8 - Casters and Brakes replacement
8-8-2-5 Rear Casters installation
1.) Loose the bolt before putting on the ramp.
2.) Align the Caster, mounting it flat and toward the back.
3.) Position the Caster so it align with the hole for the fixing bolt.
4.) Install the fixing bolt (M12 X 40 mm). Use a 10 mm HEX key, torque: 81 Nm (59.7 lbf-ft).
5.) Remove the Wooden Wedge.
6.) Roll the system off the Bevel Edged Board.
7.) To replace the other Rear Caster, repeat all the steps, starting from 8-8-2-4 "Rear Casters removal"
on page 8-193, but now using the Bevel Edged board and the Wooden Wedge on the other side of
the system.
8.) Install the Rear Cover.
9.) Install the Rear Bumper.
10.)Install the Side Covers.
8-8-2-6 Calibration and adjustments
No calibrations or adjustments are needed after this part replacement.
8-8-2-7 Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws removed earlier have been installed.
2.) If finished, connect cables and Probes removed earlier.
3.) Power up the system to verify that it starts as it should.
8-8-2-8 Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
If all are successful, include the following debrief script: LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all required checks and is ready for use.
Table 8-118 Rear Casters replacement Functional Checks
See:
Section
Functional Check Debrief Script
4-2-2 Power ON/Boot Up
LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all required
checks and is ready for use.
4-2-3 Power shut down
4-3-14 Probe/Connectors Checks
4-3-5 B-Mode Checks
4-3-7-3 Color Mode Checks
4-3-7-6 PW/CW Doppler Mode Checks
4-3-18 Mechanical Function Checks
4-2-10-1
and
4-3-18-2
The Casters (Wheels) control
and
Brakes and Direction Lock Checks
4-2-4 Top Console position adjustment
