IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
8 - 216 Section 8-9 - BEP (Back End Processor) parts replacement
8-9-3-3 Calibration and adjustments
Calibrate the Front End as described in: Section 6-6 "DC Offset Calibration" on page 6-20.
8-9-3-4 Verification
Perform the following steps to verify that the product is functioning as intended after this replacement:
1.) Verify that all screws that you removed earlier have been installed.
2.) If finished, connect cables and Probes removed earlier.
3.) Power up the system to verify that it operates as intended.
8-9-3-5 Functional Checks
Perform the following functional checks to confirm the system is operational before returning the system
to the customer.
If all are successful, include the following debrief script: LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all required checks and is ready for use.
1.) Check/Set Date, Time, and Timezone, and set the Preset Region accordingly.
2.) Reconnect to the network.
3.) If the system was connected to InSite ExC, restore the service settings backed up prior to the Base
Load. Reboot and verify remote connectivity.
4.) Confirm Patient Archive images, Report Archive, User Defined Configuration (Customer Presets),
and Service settings are restored.
5.) Format a DVD, and backup Customer Presets to confirm proper CD/DVD write functionality.
22.
Perform Functional Checks. See: 8-9-3-3 - Calibration and adjustments, 8-9-3-4 - Verification
and 8-9-3-5 "Functional Checks" on page 8-216.
Table 8-128 BEP replacement Functional Checks
See:
Section Functional Check Debrief Script
4-2-2 Power ON/Boot Up
LOGIQ E9 Service Manual, Direction
5535208-100, Rev. 2. Equipment passed all
required checks and is ready for use.
4-2-3 Power shut down
4-3-5 B-Mode Checks
4-3-7 System CFM and PWD Checks
4-3-18
Mechanical Function Checks - internal
and external
Perform a 4D sweep
Diagnostics
Table 8-127 BEP installation
Steps Corresponding Graphic
To Next Page
