IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 253
3.
If a tie wrap is not attached, attach a
second tie wrap. Position the tie wrap 3 to
5 cm (1.19 to 1.96 inches) from the end of
the cable sleeves. Trim the end of the tie
wrap.
4.
Position the wire tied cables between the
heatsink (a) and the module (b) before
placing the Fan Assembly into the PS.
Table 8-162 Installing the replacement Fan Assembly
Step Corresponding Graphic
