IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
2 - 12 Section 2-3 - Facility needs
2-3-5-5 DICOM option setup requirements (cont’d)
Figure 2-3 Worksheet for DICOM Network Information
LOGIQ E9
Host Name
AE Title
Local Port
IP Address
Net Mask
...
...
...
Default Gateway
DICOM APPLICATION
NAME
Store 2
Store 3
Store 1
MAKE/ IP PORTAE TITLE
DICOM
Print
Storage
Commit
DICOM
MPPS
Worklist
...
...
...
...
...
...
...
Network
Speed
Associated
Storage AE
_____________
__Raw Data
__Allow Multiframe
__Structured
Reporting
Compression_______
__Raw Data
__Allow Multiframe
__Structured
Reporting
Compression_______
__Raw Data
__Allow Multiframe
__Structured
Reporting
Compression_______
Vendor: ___________
Print Size: _________
Medium: ___________
Copies: ___________
Orientation: ________
Color ______________
OTHER
CONFIGURATION
DHCP

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
