GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
9 - 10 Section 9-7 - Covers and Bumpers
3a
Cover Left Assembly
5168069
OBSOLETE
Replaced by 5337050 1 Y
Cover Left Assembly
with Logo
5337050 1Y
Cover Left Assembly
with Sapphire Logo
5337050-2 1Y
4a
Top Cover GA307023
Top Cover
1Y
5a
Handle Rear GA307029-2 1Y
Table 9-10 Covers - LOGIQ E9 2 of 8 (not all covers or items listed are
identified in Figure 9-2 on page 9-9)
ITEM PART NAME PART NUMBER DESCRIPTION QTY FRU
