GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
9 - 66 Section 9-13 - Back End Processor (BEP) parts
9.
Front Module 5301222-3 1Y
10.
BEP Fan 5198607 1Y
11.
BEP Cover with Battery Tray 5270660 1Y
12.
Shock Mount HD 5267412 6Y
Table 9-27 Back End Processor parts for R3.x and earlier 3 of 4 (Continued)
ITEM PART NAME PART NUMBER DESCRIPTION QTY FRU
