GE LOGIQ E9 Service Manual

GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
9 - 104 Section 9-18 - Probes
C1-5-D H40452LE
5409287
5499513 RoHs
S1-5 H4908SC 5269878
S1-5D
(R4.x and later)
H4913SD 5438302
IC5-9-D H40442LK
5212417
5499592 RoHs
RAB 4-8 4D
Curved Array Probe
(R2.x.x)
H4865IPM
KTZ157038
KTZ303983 RoHs
M5S-D
(R2.x.x)
H45551NH GE-3MIX
P2D 2MHz
CW Pencil Probe
(R2.x.x)
H4830JE TE100024
P6D 6MHz
CW Pencil Probe
(R2.x.x)
H4830JG TQ100002
6Tc Multi-plane
Cardiac TEE Probe
(R2.x.x)
H455512D
KN100105
KN100107 RoHs
6S-DLP
Phase Array
Pediatric Probe
H45021RR 47236955
Table 9-46 Supported Probes (not including Japan Probes) 3 of 4 (Continued)
PROBES CATALOG NUMBER PART NUMBER COMMENTS
