Chapter 9 Renewal Parts 9 - 109
Section 9-19 Options (cont’d)
9-19-1 Options Compatible Configurations
See: 9-19-1-1 "LOGIQ E9 Options Compatible Configurations Key" on page 9-110.
* These options have additional hardware requirements depending on the console model.
** WLAN Dongle is not supported on R4 or later.
NOTE: Compatibility charts only show parts that have any compatibility dependencies. Parts not listed
are assumed to be compatible with all configurations.
Table 9-48 Options Compatible Configurations
Options Compatible Configurations
MODEL
NUMBER
DESCRIPTION
R1.x.x R1.x.x R1.x.x R2.x.x R2.x.x R2.x.x R2.x.x R4.xx R4 R5 R5
4D MC VNAV DVR CW* Patient I/O* Footswitch
WLAN
Dongle
**
WLAN
BEP6
BEP6
Scan
Converter*
Shear Wave*
V Nav
Inside*
5205000
LOGIQ E9
100-240 VAC
CCCC C C CC C N C
5205000-2
LOGIQ E9
220-240 VAC
CCCC C C CC C N C
5205000-3
LOGIQ E9
100-240 VAC
CCCC C C CC C N C
5205000-4
LOGIQ E9
220-240 VAC
CCCC C C CC C N C
5205000-5
LOGIQ E9
100-240 VAC
CCCC C C CC C N C
5205000-6
LOGIQ E9
220-240 VAC
CCCC C C CC C C C
5205000-7
LOGIQ E9
100-240 VAC
CCCC C C NC C C C
5205000-8
LOGIQ E9
100-240 VAC
CCCC C C NC C C C

GE LOGIQ E9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Transducer Ports	4 active ports
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Vascular, Musculoskeletal, Small Parts, Urology, Pediatric, Cardiac, Obstetrics/Gynecology
Transducers	Linear, Convex, Phased Array, Volume
Doppler Modes	Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler
Elastography	Yes
Advanced Features	B-Flow, Volume Navigation
Portability	Cart-based system
Display	19-inch high-resolution LCD monitor
