IRECTION 5394227, 12 LOGIQ S8/LOGIQ E8 SERVICE MANUAL
Section 4-1 - Overview 4 - 1
Chapter 4
Functional Checks
Section 4-1
Overview
4-1-1 Purpose of this chapter
This chapter provides procedures for quickly checking major functions of the LOGIQ S8 scanner and
diagnostics instructions using the built-in service software.
4-1-2 Contents in this chapter
4-1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4-3 General procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
4-4 Functional Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
4-5 Application Turnover Check List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
4-6 Power supply test and adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-48
4-7 Site Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-49
Section 4-2
Required equipment
• An empty (blank) CD-R, DVD-R, and/or external USB devices (Flash drive or hard disk drive).
• A blank DVD+RW disc for DVR recording (R1.x.x or R2.x.x).
• A blank DVD+RW or DVD-RW disc for DVR recording (R3.x.x or later).
• At least one probe (ideally you should check all the site probes used by the system.)
For available probes, see Section 9-13 "Probes" on page 9-59.
NOTICE
!! NOTICE:
Most of the information pertaining to this Functional Checks chapter is found in the Basic User Manual;
