4 - 8 Section 4-3 - General procedures
4-3-5-2 Monitor Arm Lock
1.) Unlock the monitor arm.
2.) Verify the monitor can move up/down (vertically) and left/right (horizontally).
3.) Align the monitor arm along center line of the system.
4.) Engage the monitor arm LOCK.
5.) Verify the monitor arm is locked and the does not move.
.
Figure 4-4 Monitor Arm Lock
Unlock Lock
