6-18 M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL

METERING CHAPTER 6: ACTUAL VALUES

The metered ground current values are displayed in this menu. The "SRC 1" text is replaced by the name programmed by

the user for the associated source (see

SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).

6.4.4.4 Phase voltage metering

ACTUAL VALUES  METERING  SOURCE SRC 1  PHASE VOLTAGE

The metered phase voltage values are displayed in this menu. The "SRC 1" text is replaced by the name programmed by

the user for the associated source (see

SETTINGS  SYSTEM SETUP  SIGNAL SOURCES).

6.4.4.5 Auxiliary voltage metering

ACTUAL VALUES  METERING  SOURCE SRC 1  AUXILIARY VOLTAGE



SRC 1 PHASOR Igd:

0.000 A 0.0°

 PHASE VOLTAGE

 SRC 1



SRC 1 RMS Vag:

0.00 V



SRC 1 RMS Vbg:

0.00 V



SRC 1 RMS Vcg:

0.00 V



SRC 1 PHASOR Vag:

0.000 V 0.0°



SRC 1 PHASOR Vbg:

0.000 V 0.0°



SRC 1 PHASOR Vcg:

0.000 V 0.0°



SRC 1 RMS Vab:

0.00 V



SRC 1 RMS Vbc:

0.00 V



SRC 1 RMS Vca:

0.00 V



SRC 1 PHASOR Vab:

0.000 V 0.0°



SRC 1 PHASOR Vbc:

0.000 V 0.0°



SRC 1 PHASOR Vca:

0.000 V 0.0°



SRC 1 ZERO SEQ V0:

0.000 V 0.0°



SRC 1 POS SEQ V1:

0.000 V 0.0°



SRC 1 NEG SEQ V2:

0.000 V 0.0°

 AUXILIARY VOLTAGE

 SRC 1



SRC 1 RMS Vx:

0.00 V



SRC 1 PHASOR Vx:

0.000 V 0.0°
