APPENDIX D: MISCELLANEOUS REVISION HISTORY
M60 MOTOR PROTECTION SYSTEM – INSTRUCTION MANUAL D-3
D
Table D-3: Major changes for M60 manual version AE3 (English)
Table D-4: Major changes for M60 manual version AE1 (English)
--- Added PEAP-GTC and PAP protocols for authenticating user logins when using a RADIUS server. Added to Settings > Product
Setup > Security > RADIUS Authentication Method and to Modbus memory map and F codes.
--- Updated Contact Inputs from 96 to 120 and Contact Outputs from 64 to 72 in Product Description in chapter 2 and FlexLogic
operands table in chapter 5
--- Updated Ground Instantaneous Overcurrent element number from 6 to 8 in FlexLogic operands table, settings, features per
product table, Modbus memory map
--- Updated Neutral Instantaneous Overcurrent element number from 4 to 12 in FlexLogic operands table, settings, features per
product table, Modbus memory map
--- Updated Neutral Time Overcurrent element number from 2 to 6 in FlexLogic operands table, settings, features per product
table, Modbus memory map
--- Updated Phase Instantaneous Overcurrent element number from 8 to 12 in FlexLogic operands table, settings, features per
product table, Modbus memory map
--- Updated Phase Time Overcurrent element number from 4 to 6 in FlexLogic operands table, settings, features per product
table, Modbus memory map
--- Updated Current CT Settings number from 4 to 6 in FlexLogic operands table, settings, features per product table, and
Modbus memory map
--- Updated Ground Instantaneous number from 6 to 12 in FlexLogic operands table, settings, features per product table,
Modbus memory map
--- Updated Ground Time Overcurrent number from 4 to 6 in FlexLogic operands table, settings, features per product table,
Modbus memory map
3-36 Updated RS422 and Fiber Interface Connection figure for the clock channels (from 7a and 7b to 1a and 1b)
3-67 Added Connect to a D400 Gateway section
4-43 Updated LED Labelling instructions for the new Front Panel Label Designer
4-50 Added Standard Front Panel section for labelling LEDs and pushbuttons
5-106 Added USB Port section to enable/disable the USB port on the graphical front panel
5-120 Updated User-programmable Pushbuttons section as per specifications
5-144 Updated Breakers section as per specifications
5-149 Updated Disconnect Switches section as per specifications
9- Added Theory of Operation chapter to include Saturation Detector section
10-5 Added Convert Device Settings section
10-7 Added Copy Settings to Other Device section
10-15 Added Replace Front Panel section for retrofit with the new graphical front panel
Page Description
--- General revision
2- Updated order codes
9-5 Added Copy Settings to Other Device section
Page Description
--- General revision
--- Added routable GOOSE content in chapters 2 and 5
3-36 Updated RS422 and Fiber Interface Connection figure for the clock channels (from 7a and 7b to 1a and 1b)
4- Added Engineer content
5- Updated IEC 61850 content
A- Updated FlexAnalog table for most UR products
