Maintenance
If the paper
size is
Then
A4 Place the pre-spacer and post-spacer along the left side of the tray.
Letter Do not place the pre-spacer and post-spacer of the tray.
While placing the spacer, make sure that the spacer is aligned in the correct
position so that the tabs at the bottom of the spacer fit into the Q holes on the
bottom of the tray, and the tabs on both sides of the spacer are affixed to the
designated tab spaces on the tray.
5. Push the paper tray back to the printer assembly.
Store Thermal Paper
When imaged and stored properly, ECG tracings resist fading for several years. If your
retention requirements exceed five years, consider using GE Archivist paper.
To ensure the tracing is imaged properly, the device must be maintained in
accordance with its service manuals and technical memoranda.
108 MAC VU360
™
Resting ECG Analysis System 2088531-370-2
