GE MAC VU360 User Manual

Product Overview
Item Name Description
13 Notification Area Displays messages:
• printing status and progress
• report transmission status
• Hookup Advisor lead quality status
The messages display one at a time in the sequence of
occurrence. The messages do not display when a patient is
connected and hookup advisor is evaluating the waveform.
14 Remote Applications Panel Displays remote applications. Select the buttons to open the
application.
15 Filter, Speed and Gain Displays the default waveform filter, speed, and gain. Select
anywhere around the ellipsis icon and select a different value.
You can only make a change before you record an ECG. You
can make a change before and during the recording of a
rhythm.
NOTE:
A change to the filter, speed or gain is applicable to the
current patient. For a new patient, the values are reset to
default settings.
16 Start Rhythm icon Select to print or digitally record the rhythm report.
17 Start ECG icon Select to record an ECG.
18 Lead Set and Display Format Displays the default test type and display format. Select
anywhere around the ellipsis icon and select a different value.
You can only make a change before you record an ECG. You
can make a change before and during the recording of a
rhythm.
NOTE:
Any change to the test type and display format only
applies to the current patient. For a new patient, the
values are reset to the default settings.
User Menu Options Description
The User Menu is located at the top right corner of the Acquisition screen.
14  MAC VU360
™
Resting ECG Analysis System 2088531-370-2

GE MAC VU360 Specifications

General

Device Type	Electrocardiograph
Power	100-240 V AC, 50/60 Hz
Battery Type	Lithium-ion
Connectivity	USB
Data Storage	Internal memory, USB drive
Sampling Rate	1000 samples per second
Battery Life	Up to 4 hours
