Recording an ECG or Rhythm
When Auto-ECG is in progress, the Start ECG button changes to the Stop ECG button:
• If you select the Stop ECG button, automatic ECG acquisition stops and the Start
ECG button displays.
• If you select the Start ECG button, ECG acquisition starts manually.
If you perform other functions during automatic ECG acquisition, a message displays
in the notification area. For example:
• If you perform Start New Patient - a message displays that unsaved data will be
lost.
• If you navigate to Settings - a message displays that cannot perform this action.
Select Cancel, to continue to perform automatic ECG acquisition and retain current
patient data. If you select Continue, automatic ECG acquisition stops.
The automatic ECG function is aborted and the device will function in manual ECG
mode if:
• An automatic ECG acquisition is stopped before 10 seconds of data is acquired.
• The preview of an ECG that was automatically acquired is rejected.
Record an ECG Manually
1. Start a test for a new patient. For more information, see Start a Test for a New
Patient on page 31.
NOTE:
If you want to record an ECG for the current patient, do not start a new
patient test.
2. Change the lead set or format, gain, speed, or filter, if required. For more
information, see Change Lead Sets and Lead Formats on page 44 and Change
Speed, Gain, and Filter on page 46.
3. Start recording the patient ECG by performing one of the following:
• Select the Start ECG icon at the bottom of the Acquisition screen:
• Press the ECG key on the keyboard:
• Press the ECG button on the Acquisition Module:
48 MAC VU360
™
Resting ECG Analysis System 2088531-370-2
