Product Overview
Item Option Description
5 Change
Password
The Admin user or a local user can change their password. Displays only if
full user authentication is enabled.
6 Lock (Alt+L) Locks the device. Displays only if full user authentication is enabled.
7 Log Out Logs off the user. Displays only when you are logged on to the device.
8 Standby Puts the device in standby mode to save battery power without turning it
off.
9 Power Off Powers off the device.
NOTE:
You can also power off the device by pressing the Power button on the
keyboard.
10 About Displays the device software information.
11 Help Displays help information about the device.
Battery Status
The battery icon shows the stored power of each battery. The power levels are shown
in 10% increments. The color of the icons change to show the level of battery life.
You may operate the device connected to the AC Mains power when the batteries
are removed. The device can also operate with a single battery installed to allow hot
swapping of the batteries without plugging into AC Power.
Table 3: Examples of Battery and Power Icon Status
Icon Status Description
Green Connected to AC
Mains
The device is connected to the AC Mains power and the
batteries are charging.
White Operating on
Battery
The device is only using batteries and the batteries are
discharging. The device is not connected to the AC Mains
power.
White Batteries – Fully
Charged
Disconnected
from AC Mains
Shows that the batteries are fully charged and the device
is disconnected from the AC Mains power. When the device
is connected to the AC Mains power and the battery icon is
solid green, shows that the battery is fully charged.
16 MAC VU360
™
Resting ECG Analysis System 2088531-370-2
