Report Formats
Item Name Description
3 12SL
Interpretation
Statements
Displays automated 12SL interpretation statements if the report
format is configured to include 12SL interpretation statements.
Clinicians use this information to make decisions about cardiac
care for the patient. The patient report includes ACS interpretation
statements when the ECG is recorded with the ACS option.
The status of Hookup Advisor is based on the 12SL analysis of the
patient report.
4 ECG Header Displays the Patient ID, date and time of ECG acquisition in the
configured date and time format, and the name of the institution, if
configured.
5 Physician
Information
Displays the following details:
• Referred by: Name of the physician who referred the patient
• Secondary ID: Alternate identification number of the patient
6 Report Status Displays the status of the report.
7 Waveforms Displays the 10 seconds ECG patient report in the configured report
format for the selected lead set.
8 Pace Spikes Displays pace spikes for patients with a pacemaker. The pace spikes
represent pacemaker pulses.
NOTE:
When two pace spikes are detected so close to each other that
they cannot be uniquely shown on the report, a single pace flag
with two flag tips is printed to indicate this condition.
9 Page Number Displays the page number of the ECG patient report in the format
page x of y, where x is the current page number and y is the total
number of pages.
10 Report Format Displays the configured report format title used to preview the ECG
patient report.
11 12SL Version Displays the 12SL version used to analyze the ECG patient report.
12 Product Model Displays the product model.
13 Filter Setting Displays the filter of the ECG waveform (measured in Hz), with Zero
Phase Distortion (ZPD for High Pass filter).
14 Gain Setting Displays the gain of the ECG waveform (measured in mm/mV).
15 Speed Setting Displays the speed of the ECG waveform (measured in mm/s).
136 MAC VU360
™
Resting ECG Analysis System 2088531-370-2
