Recording an ECG or Rhythm
Item Name Description
2 Preview of ECG patient
report
Displays the preview of the ECG patient report. If a patient report
contains multiple pages, a part of another page is displayed on
the right-side of the screen. Press the left and right arrows on the
screen to navigate from one page to another.
For more information on the report formats and the standard
layout of the ECG patient report, see ECG Report Formats on page
130.
3 Reject icon Select the Reject icon to return to the live waveform display in the
Acquisition screen.
4 Accept icon Select the Accept icon to accept the preview of the ECG patient
report and save it in the Files list. The accepted ECG patient
report is refreshed and displayed in the same tab for review with
additional options.
5 Live tab Select the Live tab to return to the live waveform displayed in
the Acquisition screen. The current ECG preview is retained until
you record another ECG, or go back to the preview and accept or
reject it.
6 Full Disclosure tab Click the Full Disclosure tab from the patient record menu bar
to navigate to the Full Disclosure waveform and application. The
ECG Preview does not change until you accept or reject the ECG
Preview or record the new ECG.
To accept or reject the ECG preview, perform the steps as follows:
1. Review the patient report and Hookup Advisor status.
2. If the CRIT option is enabled on the device, and one or more critical values
are detected during ECG acquisition, a window opens on top of the ECG tab
displaying critical value notifications in the order in which they are detected.
3. Select Continue to acknowledge each notification.
If you try to perform other functions such as accessing the Settings or Service
screen prior to accepting or rejecting the ECG, a message displays indicating that
the ECG is not saved, and the preview will be lost if you navigate to the screen.
Select one of the options as follows:
• If you select Continue, the preview will be lost.
• If you select Cancel, you can proceed to accept or reject the ECG preview.
52 MAC VU360
™
Resting ECG Analysis System 2088531-370-2
