PanaFlow™ XMT1000 User’s Manual 3
Chapter 1. Installation
1.3 Unpacking the XMT1000 (cont.)
Figure 2: Typical XMT1000 Labels (Stainless Steel Enclosure)
1.4 Site and Clearance Considerations
1.4.1 Access to the Meter
Because the relative location of the flowcell and the XMT1000 transmitter is important, use the guidelines in this
section to plan the XMT1000 installation.
For flowcell clearance recommendations, consult the manual for your specific flow meter system or contact GE for
assistance. Access to the XMT1000 flow transmitter should be uninhibited, as defined by the minimum clearance
distances around the enclosure specified in Figure 3 on page 4.
Model & Serial Number (Boston) Model & Serial Number (Shannon)
Certification (US/CAN, IECEx/ATEX)
[FISCO]
Certification (US/CAN, IECEx/ATEX)
[Standard]
To Next Page
