Appendix D. Foundation Fieldbus Communication
68 PanaFlow™ XMT1000 User’s Manual
D.5.1 Units
The measurement parameters found on the XMIT Transducer Block have several selectable units. Tabl e 8 below lists the
available units for each parameter.
Note: The units can only be changed using an
Admin password. Make sure the selected units agree between the XMIT
Transducer Block
and the AI Block.
Table 8: Available Parameters and Units in XMIT Transducer Block
Parameter Units
Density
g/m
3
, kg/L, g/ml, kg/m
3
, lb/in
3
, lb/ft
3
, lb/gal
Volumetric Flow (Act)
m
3
/s, m
3
/m, m
3
/h, m
3
/d, L/s, L/min, L/h, ML/d, CFS, CFM, CFH, ft
3
/d, gal/s, GPM,
gal/h, gal/d, ImpGal/s, ImpGal/min, ImpGal/h, ImpGal/d, bbl/s, bbl/min, bbl/h, bbl/d,
kgal/min, kgal/h, kgal/d, kbbl/min, kbbl/h, kbbl/d, ac-ft/m, ac-ft/h, ac-ft/d
Mass Flow kg/s, kg/min, kg/h, kg/d, t/s, t/min, t/h, t/d, lb/s, lb/min, lb/h, lb/d, Ston/s, Ston/min,
Ston/h, Ston/d, klb(US)/s, klb(US)/min, klb(US)/h, klb(US)/d
Velocity m/s, ft/s
Totals
m
3
, L, ft
3
, gallon, bbl, Mgal, Mft
3
, ImpGal, Mbbl, Ml, Mm
3
, ac-ft, ac-in, Sm
3
, SL, SCF
Temperature K, C, F, R
Pressure
kg-m
2
, Pa, Mpa, kPa, bar, mbar, torr, atm, psia, psig
