PanaFlow™ XMT1000 User’s Manual 25
Chapter 3. Error Codes and Troubleshooting
Chapter 3. Error Codes and Troubleshooting
3.1 Error Display in the User Interface
The bottom line of the LCD displays a single, top priority error message during Measurement Mode. This line, called
the Error Line, includes two parts: Error header and Error String. The Error header indicates the error pattern and error
number, while the Error string gives a detailed description of the error information
3.1.1 Error Header
3.1.2 Communication Error String
The XMT1000 flow transmitter electronics includes two independent sub-systems. The purpose of the Communication
error string is to convey to the operator an issue with communication between these two sub-systems.
Table 2: Error Header
Error Pattern Error Header
Communication error Cn (n is error number)
Flow error En (n is error number)
System error Sn (n is error number)
XMIT error Xn (n is error number)
OPT error On (n is error number)
Table 3: Communication Error String
Error Header Error Message
C1 Flow PCB Comm error
