PanaFlow™ XMT1000 User’s Manual 33
Appendix A. Specifications
A.2 Electronics (cont.)
Electronics Classifications (Pending)
USA/Canada- Explosion-proof Class I, Division 1, Groups B, C, & D
ATEX - Flameproof II 2 G Ex d IIC T6 Gb
IECEx - Flameproof Ex d IIC T6 Gb
RoHS compliance (Directive 2011/65/EU)
CE Marking (EMC directive 2014/30/EU, LVD 2014/35/EU)
WEEE compliance (Directive 2012/19/EU)
Electronics Mounting
Standard: Local Mounting (on meter body)
Optional: Remote Mounting (recommended for process temperatures exceeding 150°C). The maximum distance is
1000 ft (300 m) using RG-62 coaxial cable or equivalent. If longer distances are required, consult the factory for
assistance.
Terminal Blocks
Operating Temperature
–40° to 140°F (–40° to +60°C)
Note: The LCD display is only visible down to -13°F (-25°C).
Storage Temperature
–40° to 158°F (–40° to 70°C)
Humidity (Operating and Storage)
10-90% RH
Table 5: Standard Terminal Block (Output A)
I/O Type Connection Specifications
Analog Output Active Output Output current: 0-22 mA
Max load: 600 Ω
Pulse, Frequency Active Output Output voltage: 5 VDC
Max. voltage with light load: 7 VDC
RS485 Modbus RS485
Communications
Standard RS485 Communications
