GE PanaFlow XMT1000

Appendix B. Modbus Communication
36 PanaFlow™ XMT1000 User’s Manual
514 Operator eUnit_NS Global Unit group 11 for
Nano Second
unitless RW 4 INT32
516 Operator eUnit_Percent Global Unit group 12 for
Percent
unitless RW 4 INT32
518 Operator eUnit_Second Global Unit group 13 for
Second
unitless RW 4 INT32
51A Operator eUnit_StdVol Global Unit group 14 for
Standard Volumetric
unitless RW 4 INT32
51C Operator eUnit_Therm Global Unit group 15 for
Therm
unitless RW 4 INT32
51E Viewer eUnit_TotTime Global Unit group 16 for
Totalizer time
unitless RW 4 INT32
520 Operator eUnit_Totalizer Global Unit group 17 for
Totalizer
unitless RW 4 INT32
522 Operator eUnit_Unitless Global Unit group 18 for
Unitless
unitless RW 4 INT32
524 Operator eUnit_US Global Unit group 19 for
Micro Second
unitless RW 4 INT32
526 Operator eUnit_Vel Global Unit group 20 for
Velocity
unitless RW 4 INT32
528 Operator eUnit_Rey Global Unit group 21 for
Reynolds
unitless RW 4 INT32
52A Gen User eUnit_Temp Global Unit group 22 for
Temperature
unitless RW 4 INT32
52C Gen User eUnit_Pressure Global Unit group 23 for
Pressure
unitless RW 4 INT32
540 540 Viewer eSysReq_Level system request level unitless RW 4 INT32
542 Viewer eSysReq_
Password
system request password unitless RW 4 INT32
544 Viewer eSysReq_
Command
system request command unitless RW 4 INT32
546 Factory eInventory_
Command
inventory request
command
unitless RW 4 INT32
580 580 Operator ePCModbus_
Baudrate
PC MODBUS baud rate unitless RW 4 INT32
582 Operator ePCModbus_
Parity
PC MODBUS parity unitless RW 4 INT32
584 Operator ePCModbus_
Stop
PC MODBUS stop bits unitless RW 4 INT32
586 Operator ePCModbus_
Address
PC MODBUS meter addr unitless RW 4 INT32
588 Operator ePCModbus_
Bits
PC MODBUS bits per
character
unitless RW 4 INT32
58A Operator ePCModbus_
Termination
PC MODBUS termination unitless RW 4 INT32
Table 6: XMT1000 Modbus Register Map - Revision 4.19 (cont.)
Reg #
in Hex
Access
Level
Register ID Description Units RO/RW
Size in
Bytes
Format
