GE PanaFlow XMT1000

Appendix B. Modbus Communication
42 PanaFlow™ XMT1000 User’s Manual
1034 Operator eAout4_
SpanValue
Analog Out 4 Span 8 RW 4 (IEEE 32 bit)
1036 Operator eAout4_
TestValue
Analog Out 4 Test Value
(Percent of Span)
12 RW 4 (IEEE 32 bit)
1038 Operator eAout4_
BaseValue
Analog Out 4 Base Value 1, 9, 14, 17,
20
RW 4 (IEEE 32 bit)
103A Operator eAout4_
FullValue
Analog Out 4 Full Value 1, 9, 14, 17,
20
RW 4 (IEEE 32 bit)
MAIN Aout Int RW
1180 1180 Operator eAout1_Mode Analog Out 1 Operating
Mode
unitless RW 4 INT32
1182 Operator RESERVED 4 INT32
1184 Operator eAout1_Adress Analog Out 1
Measurement Register
Address
unitless RW 4 INT32
1186 Operator eAout1_Err Analog Out 1 Error
Handling
unitless RW 4 INT32
1188 Operator eAout1_Unit Analog Out 1 Unit code unitless RW 4 INT32
HART Aout Int RW
1190 1190 Operator eAout2_Mode Analog Out 2 Operating
Mode
unitless RW 4 INT32
1192 Operator eAout2_Type Analog Out 2 Type unitless RW 4 INT32
1194 Operator eAout2_Adress Analog Out 2
Measurement Register
Address
unitless RW 4 INT32
1196 Operator eAout2_Err Analog Out 2 Error
Handling
unitless RW 4 INT32
1198 Operator eAout2_Unit Analog Out 2 Unit code unitless RW 4 INT32
IO Aout1 Int RW
11A0 11A0 Operator eAout3_Mode Analog Out 3 Operating
Mode
unitless RW 4 INT32
11A2 Operator eAout3_Type Analog Out 3 Type unitless RW 4 INT32
11A4 Operator eAout3_Adress Analog Out 3
Measurement Register
Address
unitless RW 4 INT32
11A6 Operator eAout3_Err Analog Out 3 Error
Handling
unitless RW 4 INT32
11A8 Operator eAout3_Unit Analog Out 3 Unit code unitless RW 4 INT32
IO Aout2 Int RW
11B0 11B0 Operator eAout4_Mode Analog Out 4 Operating
Mode
unitless RW 4 INT32
11B2 Operator eAout4_Type Analog Out 4 Type unitless RW 4 INT32
11B4 Operator eAout4_Adress Analog Out 4
Measurement Register
Address
unitless RW 4 INT32
11B6 Operator eAout4_Err Analog Out 4 Error
Handling
unitless RW 4 INT32
Table 6: XMT1000 Modbus Register Map - Revision 4.19 (cont.)
Reg #
in Hex
Access
Level
Register ID Description Units RO/RW
Size in
Bytes
Format
