D.6 Composite Transducer Block (cont.)
Table 9: Available Measurement Values and Parameters in the Composite TB
Composite TB Measurements and Parameters Measurement Parameter
BATCH_FWD_TOTALS R
BATCH_REV_TOTALS R
BATCH_TOTAL_TIME R
SOUND_SPEED R
INVENTORY_FWD_TOTALS R
INVENTORY_REV_TOTALS R
INVENTORY_TOTAL_TIME R
MULTI_KFACTOR R
REYNOLDS_KFACTOR R
CURRENT_OPERATING_TEMP R
STANDARD_VOLUMETRIC R
BATCH_NET_TOTALS R
ERROR_STATUS R
HEALTH_CODE R
REPORTED_ERROR R
GATE_INPUT_STATE R
UNIT_TYPE_DENSITY_R R
UNIT_TYPE_VELOCITY_R R
UNIT_TYPE_TEMPERATURE_R R
PIPE_ID R/W
PIPE_OD R/W
PIPE_WALL_THICKNESS R/W
CORR_PEAK_LOW_LIMIT R/W
ANALOGOUT_PERCENTSCALE R/W
ACCELERATION_LIMIT R/W
AMP_DISC_MIN R/W
AMP_DISC_MAX R/W
KINEMATIC_VISCOSITY R/W
CALIBRATION_FACTOR R/W
ZERO_CUTOFF R/W
RESPONSE_TIME R/W
VELOCITY_LOW_LIMIT R/W
VELOCITY_HIGH_LIMIT R/W
VELOCITY_WARN_LOW_LIMIT R/W
