August 2003
7-22 Logging Data
Displaying Log Data in Graphical Form (cont.)
If you wish to alter the time scale, press [F2] (Time). The Enter
Time window appears similar to Figure 7-15 below.
Figure 7-15: The Enter Time Window
1. Use the arrow keys to scroll to the desired text box. Press
[ENTER] to open the box.
2. Two alternatives are available to change a highlighted date or
time:
•Use the numeric keys to enter the desired number.
•Use the [T] or [S] arrow keys to scroll, in 1-digit
increments, to the desired number. (For example, if the
text box displays 09, pressing the [
T] key twice
changes the number to 07.) You can scroll from 01 to 12
for the month, from 01 to 31 for the day (depending on
the number you have selected for the month), and from
0 to 59 for minutes and seconds.
In either case, press
[ENTER] to confirm the entry.
3. Repeat step 2 for any other entries you wish to change.
4. When you have finished, press
[F3] (OK) to confirm the
entries and close the window, or press
[F2] (Cancel) to leave
the window without changing the entries.
AAA.LOG (Dew Point, °C)
-52.0
Enter Time
Start Date
End Date
Start Time
End Time
2003/03/01
2003/03/01
13:53:41 PM
13:23:41 PM
