Programming Meter Settings 6-17
August 2003
Setting Up User Tables
When you program user functions (see page 3-18), you can also
support them with up to six user tables of non-linear or empirical
data. To program one or more user tables:
1. From the Meter menu, scroll to the User Tables entry and
press
[ENTER]. The window now appears similar to Figure
6-8 below.
Figure 6-8: The User Tables Window
2. The first prompt asks you to select the table to be
programmed.
a. Press
[ENTER] to open the drop-down menu.
b. Use the [
T] or [S] arrow keys to scroll to the table you
wish to program.
c. Press
[ENTER] to confirm the entry.
Programming
User Function Tables
Cancell
OK
Edit Tables
Table
Table ID
Table 1
UserTable1
# Data Points
Max Points
To Next Page
