August 2003
6-18 Programming Meter Settings
Setting up User Tables (cont.)
3. The next step is to create a Table ID.
a. Press
[ENTER] to open the window. The screen now
appears similar to Figure 6-9 below.
Figure 6-9: The Text Creation Window
b. Use the four arrow keys to scroll to the desired letter or
symbol, and press
[ENTER] to add the letter to the label.
Note: Pressing
[SEL] causes the screen to alternate between a
set of upper-case (capital) letters and a set of symbols.
Use both screens to create the desired label.
c. Repeat this procedure for each letter or symbol you wish to
add to the label. If you wish to delete a letter, press
[F1]
(Delete) to erase each letter or symbol, from right to left on
the label.
d. When you have completed the label, press
[F3] (OK) to
confirm the label, or
[F2] (Cancel) to leave the window
without adding the label.
Delete
Cancel OK
UserTable1
A B C D E F G H I J
K L M N O P Q R S T
U V W X Y Z 0 1 2 3
4 5 6 7 8 9 . , “ ‘
= < >
To Next Page
