Chapter 4. Data Sets & Reports
USM Go Operator’s Manual 125
4.8 Storing a Report
To store the report specified in the previous section:
Note: If you have chosen to store the A-Scan image with the report, the image will be saved as a JPG file.
1. Use the joystick ( ) to select the function titled FILENAME. Press the center of the joystick ( ) to activate the function.
2. Move the joystick up or down ( ) to choose the first character in the desired filename. Then, move the joystick left or right
( ) to move the cursor to a different character position in the text string.
3. Repeat step 2 until you have entered the entire file name. Then, press the center of the joystick ( ) to deactivate the function.
4. If you have not already done so, assign the COPY function to one of the Function Toggle buttons (see “Defining Function Toggle
Actions” on page 35). Your report can now be saved by pressing the assigned toggle button, whenever you are in Acquisition Mode and
the cursor is in the menu bar or the full-screen display is active.
