Chapter 3. Making Measurements
74 USM Go Operator’s Manual
3.2.1 Setting the Angle Beam Probe Parameters (cont.)
3. Use the joystick ( ) to select the THICKNESS function, and input the thickness of the test piece. The thickness of a solid rod
should be input as 1/2 of its diameter.
4. Use the joystick ( ) to select the X VALUE function, and input the user-determined X value for the probe. This compensates for
the distance from the BIP to the front of the probe wedge.
5. Use the joystick ( ) to select the O DIAMETER function, and input the outside diameter (from 50 to 2000 mm) of a curved test
piece. When set to FLAT, curvature correction is not applied.
Note: Based on the values input for the PROBE ANGLE, THICKNESS, X VALUE, and O DIAMETER parameters, the instrument
operates in one of five modes. Each of these modes is represented by an icon in the icon area at the upper left corner of the screen.
See Figure 6 on page 17 for an illustration of these icons.
