GEA EL48 - Torque Wheel Nuts; Purge Air Tank (Only with Air Brake Option); Purge Air Tank

Maintenance
Purge air tank (only with air brake option)
2018-9015-001
09-2016
124 / 192
9.13 Torque wheel nuts
Before each use or every 10 hours
Note!
It is of prime importance to check the torque of the nuts after the 3 to
5 first trips.
● Ensure wheel nuts are torqued to
375 ft-lb [508 NM];
● To torque wheel nuts, follow the
sequence illustrated.
9.14 Purge air tank (only with air brake option)
Before each use or every 10 hours
● Find the steel cable (1) located on
the side of the spreader;
● Pull cable for 3 seconds to purge oil,
water and dust from the air tank (2).
2
1
