GEA EL48 - Axle and Braking System Assembly; Axle Assembly Procedures

Handling and assembly
Axle assembly
2018-9015-001
09-2016
38 / 192
5.5 Axle assembly
If the spreader is shipped in a container, the non-directional axle may have to
be assembled.
5.5.1 Air valve removal
Note!
The suspension cylinder will extend.
1
● Unscrew the air valve (1);
● Remove the valve spring located inside the air valve to allow air release;
● Repeat these steps for each cylinder.
