Handling and assembly
Self-loading assembly (optional)
2018-9015-001
09-2016
55 / 192
5.13 Self-loading assembly (optional)
Warning!
Beware of potential falls: always walk on the nonslip band installed on
the product.
A Inner valve cylinder
B Primer pump (if applicable)
C Hose supports
Note!
The flexible suction hose is not shown in the illustration above. It is
installed on the opposite side of the spreader.
