GEA EL48 - Geometric and Tire Specifications

Technical data
Geometric data (SAE & Imperial)
2018-9015-001
09-2016
19 / 192
4 Technical data
4.1 Geometric data (SAE & Imperial)
The following tables contain approximate values. The type of manure and its composition
will significantly increase the total weight, particularly when manure contains sand.
EL48-4D
Model
Capacity
Tire
Size
Overall dimension
1
Total weight (lbs)
1
Load (lbs)
1
A B C D E Net
Full
load
2
Per
axle
2
Draw bar
2
EL48-4D
3600
3600 UK gal
4300 US gal
23.1 X 26
18 ft 86” 24 ft
113” 118” 12467 48437 22017 4403
Max 5500
28L X 26
123” 119”
13371 49341 22428 4486
725/65 X 26 13601 49571 22532 4506
850/50 X30.5 137”
122”
14009 49979 22718 4544
850/50 X 32 138.5” 14154 50124 22784 4557
EL48-4D
4000
4000 UK gal
4800 US gal
23.1 X 26
20 ft 86” 26 ft
113” 118” 13077 53117 24282 4553
Max 7700
28L X 26
123” 119”
13981 54021 24695 4630
725/65 X 26 14211 54251 24800 4650
850/50 X30.5 137”
122”
14619 54659 24987 4685
850/50 X 32 138.5” 14764 54804 25053 4697
EL48-4D
4400
4400 UK gal
5300 US gal
28L X 26
22 ft 86” 28 ft
123” 119”
14591 58591 26920 4751
Max 7700
725/65 X 26 14821 58821 27026 4769
850/50 X30.5 137”
122”
15229 59229 27213 4802
850/50 X 32 138.5” 15374 59374 27280 4814
1
Data given for a spreader including wheels, without options nor tool bar.
2
Data given for a spreader filled with water.
