GEA EL48 - Page 20

Technical data
Geometric data (SAE & Imperial)
2018-9015-001
09-2016
20 / 192
EL48-6D
Model
Capacity
Tire
Size
Overall dimension
1
Total weight (lbs)
1
Load (lbs)
1
A B C D E Net
Full
load
2
Per
axle
2
Draw bar
2
EL48-6D
4400
4400 UK gal
5300 US gal
23.1 X 26
22 ft 86” 28 ft
113” 118” 15567 59567 18246 4830
Max 7700
28L X 26
123” 119”
16922 60922 18661 4940
725/65 X 26 17266 61266 18766 4968
850/50 X30.5 137”
122”
18042 62042 19004 5030
850/50 X 32 138.5” 18259 62259 19070 5048
EL48-6D
4800
4800 UK gal
5800 US gal
23.1 X 26
24 ft 86” 30 ft
113” 118” 16177 64137 19734 4934
Max 7700
28L X 26
123” 119”
17532 65492 20151 5038
725/65 X 26 17876 65836 20257 5064
850/50 X30.5 137”
122”
18652 66612 20496 5124
850/50 X 32 138.5” 18869 66829 20563 5141
EL48-6D
5250
5250 UK gal
6300 US gal
23.1 X 26
24 ft 98” 30 ft
113” 118” 17037 69507 21387 5347
Max 7700
28L X 26
123” 119”
18388 70858 21802 5451
725/65 X 26 18071 70541 21705 5426
850/50 X30.5 137”
122”
19345 71815 22097 5524
850/50 X 32 138.5” 19561 72031 22163 5541
EL48-6D
5600
5600 UK gal
6700 US gal
23.1 X 26
28 ft 86” 34 ft
113” 118” 17397 73497 22790 5128
Max 7700
28L X 26
123” 119”
18752 74852 23210 5222
725/65 X 26 19096 75196 23317 5246
850/50 X30.5 137”
122”
19872 75972 23557 5300
850/50 X 32 138.5” 20089 76189 23624 5316
EL48-6D
6000
6000 UK gal
7200 US gal
23.1 X 26
30 ft 86” 36 ft
113” 118” 18007 78012 24270 5201
Max 7700
28L X 26
123” 119”
19362 79367 24692 5291
725/65 X 26 19706 79711 24799 5314
850/50 X30.5 137”
122”
20482 80487 25040 5366
850/50 X 32 138.5” 20699 80704 25108 5380
