Appendix
Hydraulic diagram - Solenoid valves control option
2018-9015-001
09-2016
166 / 192
11.10 Hydraulic diagram - Solenoid valves control option
2
3
1
6
5
4
Legend:
1 Solenoid valve 4 Hydraulic component #2
2 Selector switch 5 Tractor hydraulic outlets
3 Hydraulic component #1 6 Tractor electric connection (12VDC)
