GEA EL48 - Bolt Torque and Lubricant Specifications

Technical data
Lubricant specifications
2018-9015-001
09-2016
33 / 192
4.7 Bolt torque chart
Note!
Refer to the bolt torque chart below unless otherwise specified in this manual.
Bolt Mat.
Bolt diameter
1/4” 5/16” 3/8” 7/16” 1/2” 9/16” 5/8” 3/4” 7/8” 1”
SAE 2
LCS
6 ft-lb
8NM
12ft-lb
16NM
20ft-lb
27NM
32ft-lb
44NM
47ft-lb
64NM
69ft-lb
94NM
96ft-lb
130NM
155ft-lb
210NM
206ft-lb
279NM
310ft-lb
420NM
SAE 5
MCS
HT
10ft-lb
14NM
19ft-lb
26NM
33ft-lb
45NM
54ft-lb
73NM
78ft-lb
106NM
114ft-lb
155NM
154ft-lb
209NM
257ft-lb
349NM
382ft-lb
518NM
587ft-lb
796NM
SAE 8
MCAS
14ft-lb
19NM
29ft-lb
39NM
47ft-lb
64NM
78ft-lb
106NM
119ft-lb
161NM
169ft-lb
229NM
230ft-lb
312NM
380ft-lb
515NM
600ft-lb
814NM
700ft-lb
949NM
Socket
Head
Cap
Screw
AS
HT
16ft-lb
22NM
33ft-lb
45NM
54ft-lb
73NM
84ft-lb
114NM
125ft-lb
170NM
180ft-lb
244NM
250ft-lb
339NM
400ft-lb
542NM
640ft-lb
868NM
970ft-lb
1315NM
4.8 Lubricant specifications
Lubricant type Product name Grade Purpose
Grease PRECISION
TM
XL5 MOLY EP2 2
● To lubricate the equipment.
● To grease the power steering
mechanism.
● To lubricate the slack adjuster.
Gearbox oil TRAXON
TM
80W-90 ● To fill the bearing housing.
Grease 880 Crown and Chassis 2 ● To grease wheel hub bearings.
Brake fluid DOT3 brake fluid ● To fill the master cylinder.
Hydraulic fluid HYDREX
TM
MV 22
● To fill suspension cylinders
bottom translucent hose.
Biodegradable oil
● To lubricate the primer pump
piston.
● To spray over the spreader
before storing.
