Handling and assembly
Handling the product
2018-9015-001
09-2016
37 / 192
Warning!
Always keep the spreader lifted while laying on the support stands (not
supplied by GEA) and make sure the support stands can withstand the
spreader weight.
2
● Position the spreader on support stands (2);
● Remove the transport stands and the wrapping that may cover components
fixed to the spreader;
● Remove the cotter pin (3) and the
washer (4);
● Remove the locking plate (5) from
each cylinder and discard the plate;
● Reinstall the cotter pin and washer.
5
3
4
