Operating
Connecting the spreader
2018-9015-001
09-2016
90 / 192
● Connect the power steering
mechanism (6) to the draw bar
assembly using provided hardware;
6
● Connect the power steering rod (7)
to the power steering mechanism (6)
using the lock pin and the washer;
● Connect the spreader hydraulic
hoses to the tractor to operate the
power steering system.
7
6
Safety chains connection
● Attach safety chains between the
tractor and the spreader draw bar.
Follow local regulations;
● Remove the manual jack or retract
the hydraulic jack;
● Remove the wheel chocks.
