Operating
Connecting the spreader
2018-9015-001
09-2016
92 / 192
Maximum angle of PTO joints
Constant velocity PTO driveline
● One PTO joint must be set at a
maximum of 70° angle. The other
PTO joint must be set at a
maximum of 10° angle.
Standard PTO driveline
● Both PTO joints must be set at the
same angle (maximum 15° angle);
Vibration
O.K.
15°
maximum
15°
maximum
70°
maximum
10°
maximum
● Joints must always be directed
toward the same side of the
driveline.
Lubrication
● For universal joints, use a high quality grease formulated for intensive use.
Follow the instructions of the PTO manufacturer for proper lubrication.
7.4.3 Connecting the components
Attention!
Connect the hydraulic and pneumatic hoses properly to ensure safe
operation. Refer to section Appendix.
● Connect the spreader hydraulic hoses and/or pneumatic hoses to the
tractor. Double check all connections for safety purpose;
● Connect the electrical outlet of the spreader to the tractor.
