Item Designation Material DN 80
3" OD
DN 100
4" OD
DN 125 DN 150
A Actuator BFV-7 / NC/NO/ cpl. -- 224-001505 224-001660 224-001509 224-001509
A (opt.) Actuator BFV-7 / AA/ cpl. (air/air) -- 224-001506 224-001506 224-001508 224-001508
3 Console BFV-7 1.4301 224-001042 224-001042 224-001071 224-001071
5* Cheese head screw A2-70 902-099 902-099 902-099 902-099
6
Elbow screw-in plug connection, metric
(1/8"-6/4)
Brass/nickel-
plated
933-475 933-475 933-475 933-475
Elbow screw-in plug connection
(1/8"-6.35)
Brass/nickel-
plated
933-979 933-979 933-979 933-979
6.1
Throttle check valve, exhaust air 1/8"
Brass/nickel-
plated
603-042 603-042 603-042 603-042
6.2 Screw-in plug connection, metric
(1/8"-6/4)
Ms CV 933-176 933-176 933-176 933-176
Screw-in plug connection, metric
(1/8"-6.35)
Ms CV 933-173 933-173 933-173 933-173
7 Elbow screw-in plug connection, metric
(1/4"-6/4)
Brass/nickel-
plated
933-034 933-034 933-034 933-034
Elbow screw-in plug connection
(1/4"-6.35)
Brass/nickel-
plated
933-972 933-972 933-972 933-972
7.1 Throttle check valve, exhaust air 1/4" Brass/nickel-
plated
603-048 603-048 603-048 603-048
7.2 Screw-in plug connection, metric
(1/4"-6/4)
Ms CV 933-480 933-480 933-480 933-480
Screw-in plug connection, metric
(1/4"-6.35)
Brass/nickel-
plated
933-477 933-477 933-477 933-477
8 Hex nut A2-70 910-018 910-018 910-018 910-018
9 Initiator M12x1; 10-65V/DC/2wire Synthetic
material
505-035 (electrical connection with terminal compartment)
Initiator M12x1; 10-30V/DC/3wire 1.4301 505-088 (electrical connection with terminal compartment)
505-096 (electrical connection with M12 plug)
11 Position indicator BFV-7 PP 224-001069 224-001069 224-001070 224-001070
12 O-ring NBR 930-024 930-024 930-024 930-024
13 Plain bearing form S IGLIDUR-F 704-074 704-074 704-074 704-074
14 O-ring NBR 930-041 930-041 930-041 930-041
* The Allen screw (5) must be ordered separately.
A includes positions A, 3, 8, 11, 12, 13, and 14
Item Material Designation Material no.
Accessories for T.VIS M-15
B Control top type T.VIS M-15 1 1.4301 Switch bar T.VIS 224-001697
Accessories for T.VIS P-15 and A-15
C Control top type T.VIS P-15
and A-15
240 -- Switch bar for T.VIS P-15 and A-15 224-001696
Accessories for control top SES/EX
E Control top SES/EX 220
Switch bar 224-001548
182
Extension 224-001549
Spare parts list - Pneumatic actuator
430BAL009990EN_2
60 30.01.2018
