GEA T-smart 7 User Manual

Item Designation Dimension
DN 15
0.5" OD
DN 20
0.75" OD
DN 25
1" OD
DN 40
1.5" OD
DN 50
2" OD
2a Threaded flange RJT C5 OD -- -- 44 44 44
G5 OD -- -- 45.7x1/8 58.4x1/8 72.7x1/6
Internal Ø DN 16 20 26 38 50
Internal Ø OD 9.5 15.85 22.2 34.9 47.6
2b Threaded flange IDF C5 OD -- -- 41 41 41
G5 OD -- -- Tr 37.1x1/8 Tr 50,6x1/8 Tr 64.1x1/8
Internal Ø DN 16 20 26 38 50
Internal Ø OD 9.5 15.85 22.2 34.9 47.6
2c/1 Threaded flange SMS C7/1 OD -- -- 36 41 41
G7/1 OD -- -- Rd 40x1/6 Rd 60x1/6 Rd 70x1/6
Internal Ø DN 16 20 26 38 50
Internal Ø OD 9.5 15.85 22.2 34.9 47.6
2c/2 Threaded flange DS C7/2 OD -- -- 38 38 40
G7/2 OD -- -- Rd 44x1/6 Rd 58x1/6 Rd 72x1/6
Internal Ø DN 16 20 26 38 50
Internal Ø OD 9.5 15.85 22.2 34.9 47.6
Switch rod
stroke
56 56 56 56 56
Disc square 10 10 10 10 10
Dimension sheet - T-smart 7
430BAL009990EN_2
30.01.2018 85
