GEA T-smart 7 User Manual

Item Designation Dimension
DN 65
2.5" OD
DN 80
3" OD
DN 100
4" OD
DN 125 DN 150
A1 Pneumatic actuator with T.VIS
control top, installation dimension X
Ø B / DN
Ø B / OD
120
116
135
128
155
160
191
--
219
--
C 10 10 10 13 14
D / actuator Ø 88.9 88.9 88.9 114.3 114.3
H / DN
H / OD
434.5
436.5
440.5
444
456.5
454
472
--
486
--
Ø LK 1 DN
Ø LK 1 OD
107
103
122
115
142
147
175
--
200
--
Bolts DN
Bolts OD
6x M8x30
4x M8x30
6x M8x30
6x M8x30
6x M8x30
6x M8x30
6x M10x40
--
8x M12x45
--
X / DN
X / OD
454.5
456.5
460.5
464
476.5
474
492
--
506
--
A2 Pneumatic actuator without control
top, installation dimension X1
Ø B / DN
Ø B / OD
120
116
135
128
155
160
191
--
219
--
D / actuator Ø 88.9 88.9 88.9 114.3 114.3
H1 / DN
H1 / OD
272.5
274.5
278.5
282
294.5
292
310
--
324
--
X1 / DN
X1 / OD
292.5
294.5
298.5
302
314.5
312
330
--
344
--
A3 Manual actuator, installation
dimension X2
Ø B / DN
Ø B / OD
120
116
135
128
155
160
191
--
219
--
Q 116 160 160 220 220
H2 / DN
H2 / OD
103
105
114.5
118
128
130.5
146
--
--
--
X2 / DN
X2 / OD
123
125
134.5
138
148
150.5
166
--
180
--
4a Intermediate flange design C8 DIN 47.5 47.5 47.5 55.0 60.0
C8 OD 47.5 47.5 47.5 -- --
C9 DIN 22.5 22.5 22.5 30.0 30.0
C9 OD 22.5 22.5 22.5 -- --
Ø LK 2/DN 107 122 142 175 200
Ø LK 2/OD 103 115 147 -- --
Bolts 4x M8x30 4x M8x30 2x M8x30 2x M10x35 2x M12x40
Internal Ø DN 66 81 100 125 150
Internal Ø OD 60.3 73 97.6 -- --
Switch rod
stroke
56 56 56 56 56
Disc square 10 12 12 14 14
Dimension sheet - Butterfly valve T-smart 7 VV
430BAL009990EN_2
90 30.01.2018
