Nominal width Material Material D1 D2 B
DN 15 EPDM 224-170.61
22.2 36.0 20.5
FKM 224-170.75
HNBR 224-170.89
VMQ 224-173.05
DN 20 EPDM 224-170.61
22.2 36.0 20.5
FKM 224-170.75
HNBR 224-170.89
VMQ 224-173.05
DN 25 EPDM 224-170.67
26.0 40.0 20.5
FKM 224-170.81
HNBR 224-170.95
VMQ 224-173.11
DN 40 EPDM 224-170.68
38.0 53.0 21.5
FKM 224-170.82
HNBR 224-170.96
VMQ 224-173.12
DN 50 EPDM 224-170.69
50.0 66.0 22.5
FKM 224-170.83
HNBR 224-170.97
VMQ 224-173.13
DN 65 EPDM 224-170.70
66.0 83.2 25.0
FKM 224-170.84
HNBR 224-170.98
VMQ 224-173.14
DN 80 EPDM 224-170.71
81.0 99.0 28.0
FKM 224-170.85
HNBR 224-170.99
VMQ 224-173.15
DN 100 EPDM 224-170.72
100.0 120.0 30.0
FKM 224-170.86
HNBR 224-173.02
VMQ 224-173.16
DN 125 EPDM 224-170.73
125.0 147.0 33.0
FKM 224-170.87
HNBR 224-173.03
VMQ 224-173.17
DN 150 EPDM 224-170.74
150.0 172.0 35.0
FKM 224-170.88
HNBR 224-173.04
VMQ 224-173.18
Dimension sheet - Butterfly valve T-smart 7 - flanges
430BAL009990EN_2
92 30.01.2018
